The Pipe Beveller OCM 2163 & OCM 2080 Is Used For The Preparation Of Pipe Ends, I.E. To Cut Edges At Individual Pipes Or Membrane Walls. Next To Its Conventional Design In Which The Motor And The Milling Spindle Are Arranged In Line, The Machine Can Be Featured With An Angular Drive On Request. Therefore, It Can Be Used In Different Situations With Limited Space.
| Drive | Pneumatic | Electric |
|---|---|---|
| Locking Range (mm) | 20-63.5 | 20-63.5 |
| Ideal Speed (RPM) | 110 | 125 |
| Torque (Nm) | 220 | 240 |
| Feeding Stroke (mm) | 25 | 25 |
| Pneumatic Power (HP) | 1.0 | -- |
| Air Consumption (cfm) | 40 | -- |
| Air Pressure (psi) | 90 | -- |
| Electric Power (watts) | -- | 1300 |
| Weight (kg) | 26.5 | 30.0 |
| Max Wall Thickness (mm) | 12 | 12 |
| Voltage | -- | 220-240 |
| Weight (Kg) | 10.5 | 9.5 |
